Special Features:
1. Meanwell Driver with 5-7 years lifetime
Meanwell Driver with unique technology , lasting 5-7 years.So our LED streetlight lifespan can reach 40,000 hours, and according to 12 hours working per day, it can be constantly used for more than 5-year.
2, LED
A, Original 45mil Bridgelux LED
B， High CRI： 80
C， Super bright LED , over 120Lm/w
3.Build-in Z –Diodes
Even if one led failed, the remaining LEDs will still work.
4.Warranty Policy
5 years warranty with original written warranty ; 20,000 switch cycles(on/off switching).
5, Simple
It is easy to use and install with the instruction manual .
Technical Specification:
|
Item NO.
|
HB-ST180W
|
|
LED power
|
180w
|
|
LED Source
|
Bridgelux LED
|
|
LED Initial Flux
|
21600Lm
|
|
Power Efficiency
|
90%
|
|
Luminous Uniformity
|
﹥0.6
|
|
Color Temperature
|
WW
|
2700-3000K
|
|
NW
|
4000-4500K
|
|
CW
|
6000-6500
|
|
Average CRI
|
WW
|
Ra﹥80
|
|
CW
|
Ra﹥75
|
|
Bean Angle
|
Horizontal Axis:120
Vertical Axis :80
|
|
Light Distribution Curve (Beam Pattern)
|
Asymmetric(Bat Wing )/Rectangular Beam
|
|
Input Voltage
|
90~265VAC
|
|
Frequency Range
|
50/60HZ
|
|
Power Factor (PF)
|
﹥0.95
|
|
Total Harmonic Distribution(THD)
|
﹤16%
|
|
Storage Temperature
|
-40℃--+80℃
|
|
Working Environment
|
-40℃--+50℃:10%-95%RH
|
|
Junction Temperature (Tj)
|
60℃±10%(ta=25℃)
|
|
Light Body and Lampshade Material
|
Aluminum Alloy and PC
|
|
Working Lifetime
|
﹥50000hrs
|
|
IP Rating
|
IP 65
|
|
Weight
|
14kg
|
|
Product Size (mm)
|
942*350*100mm
|
